Telemetry/Logging Information¶
Data Sensors Available:¶
- Window Event Logs (Application, Security, System, Setup)
- Security events are being configured/audited via GPO.
- Sysmon
- Configuration is being pulled from Olaf Hartong’s sysmon-modular project
- Zeek
- Logs are stored within the Marvel-Lab directory you created under:
Marvel-Lab/Logging/splunk/zeek/zeek-logs
- Logs are stored within the Marvel-Lab directory you created under:
- OSQuery (Mac and Windows)
- Configs are coming from: https://github.com/palantir/osquery-configuration
Analytic Platforms:¶
- Splunk
- We recommend getting the Developer License Splunk offers and applying it within this lab due to the robustness of logs being collected.
- Jupyter Notebooks
Current data sources being shipped to Splunk:¶
- Windows Events (Window Event Logs (Application, Security, System, Setup) (Windows Workstations)
- Sysmon (Windows Workstations)
- Zeek
- OSQuery (Windows/MacOS Workstations)
Splunk Universal Forwarder:¶
The Forwarder currently has some exclusions set within the inputs.conf. These can be found below:
Event ID 4688:
blacklist1=EventCode="4688" Message="New Process Name:\s*(?i)(?:[C-F]:\\Program Files\\Splunk(?:UniversalForwarder)?\\bin\\(?:btool|splunkd|splunk|splunk\-(?:MonitorNoHandle|admon|netmon|perfmon|powershell|regmon|winevtlog|winhostinfo|winprintmon|wmi|optimize))\.exe)"
Rule was borrowed from: https://gist.github.com/automine/a3915d5238e2967c8d44b0ebcfb66147
Event ID 4689:
blacklist2=EventCode="4689" Message="Process Name:\s*(?i)(?:[C-F]:\\Program Files\\Splunk(?:UniversalForwarder)?\\bin\\(?:btool|splunkd|splunk|splunk\-(?:MonitorNoHandle|admon|netmon|perfmon|powershell|regmon|winevtlog|winhostinfo|winprintmon|wmi|optimize))\.exe)"
Rule was borrowed from: https://gist.github.com/automine/a3915d5238e2967c8d44b0ebcfb66147
Event ID 5156:
blacklist3=EventCode="5156" Message="(?ms)Application\sName:\s.*\\windows\\system32\\svchost.exe."
